Clock7d2Ch (FB)

FUNCTION_BLOCK Clock7d2Ch

Functional Description

7 weekday time switch, two switch-on / switch-off points in time and a binary total output.
The mode of operation (switch-on period or switch-off period) can be defined per weekday.
Typical application: Defining the night / day operation of a zone temperature control

Portrayal

../_images/Clock7d2Ch_FB.png

Interfaces

Inputs

Name

Datatype

Range

Init-Value

Function
xEn BOOL

Enable input

Outputs

Name

Datatype

Range

Init-Value

Function
xActive BOOL

Current Switching periods
todActivatedFrom TOD

Switch-on point in time 1 of the current weekday
todActivatedTo TOD

Switch-off point in time 2 of the current weekday

Setpoints / Parameters

Name

Datatype

Range

Init-Value

Function
todMonFrom1 TOD   TOD#07:00

Switch-on point in time 1 - Monday
todMonTo1 TOD   TOD#12:00

Switch-off point in time 1 - Monday
todMonFrom2 TOD   TOD#12:00

Switch-on point in time 2 - Monday
todMonTo2 TOD   TOD#18:00

Switch-off point in time 2 - Monday
xMonMode BOOL   TRUE

Mode - Switching periods - Monday
todTueFrom1 TOD   TOD#07:00

Switch-on point in time 1 - Tuesday
todTueTo1 TOD   TOD#12:00

Switch-off point in time 1 - Tuesday
todTueFrom2 TOD   TOD#12:00

Switch-on point in time 2 - Tuesday
todTueTo2 TOD   TOD#18:00

Switch-off point in time 2 - Tuesday
xTueMode BOOL   TRUE

Mode - Switching periods - Tuesday
todWedFrom1 TOD   TOD#07:00

Switch-on point in time 1 - Wednesday
todWedTo1 TOD   TOD#12:00

Switch-off point in time 1 - Wednesday
todWedFrom2 TOD   TOD#12:00

Switch-on point in time 2 - Wednesday
todWedTo2 TOD   TOD#18:00

Switch-off point in time 2 - Wednesday
xWedMode BOOL   TRUE

Mode - Switching periods - Wednesday
todThuFrom1 TOD   TOD#07:00

Switch-on point in time 1 - Thursday
todThuTo1 TOD   TOD#12:00

Switch-off point in time 1 - Thursday
todThuFrom2 TOD   TOD#12:00

Switch-on point in time 2 - Thursday
todThuTo2 TOD   TOD#18:00

Switch-off point in time 2 - Thursday
xThuMode BOOL   TRUE

Mode - Switching periods - Friday
todFriFrom1 TOD   TOD#07:00

Switch-on point in time 1 - Friday
todFriTo1 TOD   TOD#12:00

Switch-off point in time 1 - Friday
todFriFrom2 TOD   TOD#12:00

Switch-on point in time 2 - Friday
todFriTo2 TOD   TOD#18:00

Switch-off point in time 2 - Friday
xFriMode BOOL   TRUE

Mode - Switching periods - Friday
todSatFrom1 TOD   TOD#07:00

Switch-off point in time 1 - Saturday
todSatTo1 TOD   TOD#12:00

Switch-off point in time 1 - Saturday
todSatFrom2 TOD   TOD#12:00

Switch-off point in time 2 - Saturday
todSatTo2 TOD   TOD#18:00

Switch-off point in time 2 - Saturday
xSatMode BOOL   TRUE

Mode - Switching periods - Saturday
todSunFrom1 TOD   TOD#07:00

Switch-on point in time 1 - Sunnday
todSunTo1 TOD   TOD#12:00

Switch-off point in time 1 - Sunnday
todSunFrom2 TOD   TOD#12:00

Switch-on point in time 2 - Sunnday
todSunTo2 TOD   TOD#18:00

Switch-off point in time 2 - Sunnday
xSunMode BOOL   TRUE

Mode - Switching periods - Sunday
sNotice STRING

‘Own Notice - click to change.’

Designation - Time switch

Functional Description

General

Weekdays 1 - 7 (Monday ... Sunday, XXX = Mon, Tue, Wed, Thu, Fri, Sat, Sun)

Each of the seven days of the week are assigned two separate switching periods (Switching period 1, Switching period 2).

Each switching period 1 is defined by adjustable data (todXXXTimeFrom1 Switch-on point in time 1 and todXXXTimeTo1 Switch-off point in time 1).
Each switching period 2 is defined by adjustable data (todXXXTimeFrom2 Switch-on point in time 2 and todXXXTimeTo2 Switch-off point in time 2).
In addition, an operating mode ( xXXXMode) can be defined.

If the switch-off point in time 1 is before the switch-on point in time 1, the switch-off point in time 1 is set to the value of the switch-on point in time 1 for the check.
If the switch-on point in time 2 is before the switch-off point in time 1, the switch-on point in time 2 is set to the value of the switch-off point in time 1 for the check.
If the switch-off point in time 2 is before the switch-on point in time 2, the switch-off point in time 2 is set to the value of the switch-on point in time 2 for the check.

A switching period is active if the current time on weekday XXX is within the switching periods of weekday XXX ( **xXXXMode**= TRUE).
A switching period is active if the current time on weekday XXX is outside the switching periods of weekday XXX ( **xXXXMode**= FALSE).

Special case: Switch-on point in time 1 = Switch-on point in time 2 = Switch-off point in time 1 = Switch-off point in time 2 = TOD#00:00

If the switch-on period (xXXXMode = TRUE) is active, the switching period is inactive the whole day.
If the switch-off period (xXXXMode = FALSE) is active, the switching period is active the whole day.

Special case: Switch-on point in time 1 = Switch-on point in time 2 = Switch-off point in time 1 = Switch-off point in time 2 = TOD#23:59

If the switch-on period (xXXXMode = TRUE) is active, the switching period is active the whole day.
If the switch-off period (xXXXMode = FALSE) is active, the switching period is inactive the whole day.

Switch-on periods

../_images/Clock7d2Ch_Bild_1.png

Switch-off periods

../_images/Clock7d2Ch_Bild_2.png

Enabling input xEN

xEn xActive todActivatedFrom todActivatedTo

Notes
FALSE FALSE

unchanged

unchanged

FB deactivated
TRUE

Condition depending on weekday, time and switching periods

Switch-on point of time the switching period 1 of the current weekday

Switch-off point of time the switching period 2 of the current weekday

FB activated

Display output xActive

The xActive display output assumes the status TRUE if the time on weekday XXX when the enable input ( xEn = TRUE) is active
lies within the switching period 1 or the switching period 2 of the weekday XXX (xXXXMode = TRUE, switch-on period).
The xActive display output assumes the status TRUE if the time on weekday XXX when the enable input ( xEn = TRUE) is active
lies outside the switching period 1 or the switching period 2 of the weekday XXX (xXXXMode = TRUE, switch-off period).
In all other cases, the xActive display output assumes the status FALSE.

xEn xActive

Switching periods XXX

 xXXXMode - XXX

Notes
FALSE FALSE X X

FB deactivated
TRUE FALSE FALSE TRUE

Switch-on periods inactive
TRUE TRUE TRUE TRUE

Switch-on periods active
TRUE TRUE FALSE FALSE

Switch-off periods inactive
TRUE FALSE TRUE FALSE

Switch-off periods active

todActivatedFrom switch-on point in time of the switching periods of the current day of the week

This output permanently indicates the switch-on point in time of the switching period 1 of the current day of the week, if the enable input (xEn = TRUE) is active.
In all other situations, it is not changed. In special cases 1 and 2, the value TOD#00:00 is always displayed.

todActivatedTo switch-off point in time of the switching periods of the current day of the week

This output permanently indicates the switch-off point in time of the switching period 2 of the current day of the week, if the enable input (xEn = TRUE) is active.
In all other situations, it is not changed. In special case 1, the value TOD#00:00 is always displayed. In special case 2, the value TOD#23:59 is displayed.

Visualization




Information

Element

Authors

Date

 Version

Notes

Function

 Adam Bartod XX.xxxx 1.0

Initial version

Programming

 Adam Bartod xx.xxxx 1.0

Initial version
Test Jochen Reu 10.2017 1.0

Initial version

Documentation

 Jochen Reu 10.2017 1.0

Initial version

Codesys

InOut:
Scope Name Type Initial Comment
Input xEn BOOL

Enable input
todMonFrom1 TOD TIME_OF_DAY#7:0

Switch-on point in time 1 - Monday
todMonTo1 TOD TIME_OF_DAY#12:0

Switch-off point in time 1 - Monday
todMonFrom2 TOD TIME_OF_DAY#12:0

Switch-on point in time 2 - Monday
todMonTo2 TOD TIME_OF_DAY#18:0

Switch-off point in time 2 - Monday
xMonMode BOOL TRUE

Mode - Switching periods - Monday
todTueFrom1 TOD TIME_OF_DAY#7:0

Switch-on point in time 1 - Tuesday
todTueTo1 TOD TIME_OF_DAY#12:0

Switch-off point in time 1 - Tuesday
todTueFrom2 TOD TIME_OF_DAY#12:0

Switch-on point in time 2 - Tuesday
todTueTo2 TOD TIME_OF_DAY#18:0

Switch-off point in time 2 - Tuesday
xTueMode BOOL TRUE

Mode - Switching periods - Tuesday
todWedFrom1 TOD TIME_OF_DAY#7:0

Switch-on point in time 1 - Wednesday
todWedTo1 TOD TIME_OF_DAY#12:0

Switch-off point in time 1 - Wednesday
todWedFrom2 TOD TIME_OF_DAY#12:0

Switch-on point in time 2 - Wednesday
todWedTo2 TOD TIME_OF_DAY#18:0

Switch-off point in time 2 - Wednesday
xWedMode BOOL TRUE

Mode - Switching periods - Wednesday
todThuFrom1 TOD TIME_OF_DAY#7:0

Switch-on point in time 1 - Thursday
todThuTo1 TOD TIME_OF_DAY#12:0

Switch-off point in time 1 - Thursday
todThuFrom2 TOD TIME_OF_DAY#12:0

Switch-on point in time 2 - Thursday
todThuTo2 TOD TIME_OF_DAY#18:0

Switch-off point in time 2 - Thursday
xThuMode BOOL TRUE

Mode - Switching periods - Friday
todFriFrom1 TOD TIME_OF_DAY#7:0

Switch-on point in time 1 - Friday
todFriTo1 TOD TIME_OF_DAY#12:0

Switch-off point in time 1 - Friday
todFriFrom2 TOD TIME_OF_DAY#12:0

Switch-on point in time 2 - Friday
todFriTo2 TOD TIME_OF_DAY#18:0

Switch-off point in time 2 - Friday
xFriMode BOOL TRUE

Mode - Switching periods - Friday
todSatFrom1 TOD TIME_OF_DAY#7:0

Switch-off point in time 1 - Saturday
todSatTo1 TOD TIME_OF_DAY#12:0

Switch-off point in time 1 - Saturday
todSatFrom2 TOD TIME_OF_DAY#12:0

Switch-off point in time 2 - Saturday
todSatTo2 TOD TIME_OF_DAY#18:0

Switch-off point in time 2 - Saturday
xSatMode BOOL TRUE

Mode - Switching periods - Saturday
todSunFrom1 TOD TIME_OF_DAY#7:0

Switch-on point in time 1 - Sunnday
todSunTo1 TOD TIME_OF_DAY#12:0

Switch-off point in time 1 - Sunnday
todSunFrom2 TOD TIME_OF_DAY#12:0

Switch-on point in time 2 - Sunnday
todSunTo2 TOD TIME_OF_DAY#18:0

Switch-off point in time 2 - Sunnday
xSunMode BOOL TRUE

Mode - Switching periods - Saturday
sNotice STRING

‘Own Notice - click to change.’

Designation - Time switch
Output xActive BOOL

Current Switching periods
todActivatedFrom TOD

Switch-on point in time 1 of the current weekday
todActivatedTo TOD

Switch-off point in time 2 of the current weekday
