# MELCloud Control [](https://github.com/homebridge/homebridge/wiki/Verified-Plugins) [](https://www.npmjs.com/package/homebridge-melcloud-control) [](https://www.npmjs.com/package/homebridge-melcloud-control) [](https://www.npmjs.com/package/homebridge-melcloud-control) [](https://github.com/grzegorz914/homebridge-melcloud-control/pulls) [](https://github.com/grzegorz914/homebridge-melcloud-control/issues) ## Package Requirements | Package | Installation | Role | Required | | --- | --- | --- | --- | | [Homebridge v2.0.0](https://github.com/homebridge/homebridge) | [Homebridge Wiki](https://github.com/homebridge/homebridge/wiki) | HomeKit Bridge | Required | | [Homebridge UI](https://github.com/homebridge/homebridge-config-ui-x) | [Homebridge UI Wiki](https://github.com/homebridge/homebridge-config-ui-x/wiki) | Homebridge User Interface | Required plugin | | [MELCloud](https://github.com/grzegorz914/homebridge-melcloud-control) | [Plug-In Wiki](https://github.com/grzegorz914/homebridge-melcloud-control/wiki) | Plug-In | Required | ## Warning * For plugin < v4.6.0 use Homebridge UI <= v5.5.0. * For plugin >= v4.6.0 use Homebridge UI >= v5.13.0. ### About The Plugin * Support: * Devices connected to MELCloud or MELCloud Home. * Multiple accounts, buildings, floors, areas. * Temperature display units `Celsius/Fahrenheit`. * Assing individual operating mode for `Heat/Cool/Auto`. * Presets, only MELCloud. * Scenes, only MELCloud Home. * Frost protection, only MELCloud Home. * Overheat Protection, only MELCloud Home. * Holiday Mode, only MELCloud Home. * Physical lock controls `LOCK/UNLOCK`, only MELCloud. * Functions, using extra `Buttons`, switch to `OFF` restore previous state. * Automations, shortcuts and Siri. * External integrations, [RESTFul](https://github.com/grzegorz914/homebridge-melcloud-control?tab=readme-ov-file#restful-integration), [MQTT](https://github.com/grzegorz914/homebridge-melcloud-control?tab=readme-ov-file#mqtt-integration). * Control devices over local network You need use ESP module and [Tasmota Control](https://github.com/grzegorz914/homebridge-tasmota-control) plugin. ### Control Mode * Air Conditioner: * Heater Cooler: * Power `ON/OFF`. * Operating mode `AUTO/HEAT/COOL/POWER OFF`. * Temperature `HEATING/COOLING/AUTO`. * Fan speed `AUTO/1/2/3/4/5`. * Swing mode `AUTO/SWING`. * Physical lock controls `LOCK/UNLOCK`. * Temperature display unit `°F/°C`. * Thermostat: * Power `ON/OFF`. * Operating mode `POWER OFF/HEAT/COOL/AUTO`. * Temperature `HEATING/COOLING/AUTO`. * Temperature display unit `°F/°C`. * Buttons: * For direct device control. * Power `ON/OFF`. * Operating mode `HEAT/DRY/COOL/FAN/AUTO`. * Physical lock controls `LOCK/UNLOCK` * Vane H mode `AUTO/1/2/3/4/5/SPLIT/SWING`. * Vane V mode `AUTO/1/2/3/4/5/SWING`. * Fan speed mode `AUTO/1/2/3/4/5`. * Preset `SET/UNSET` * Frost protection `ON/OFF/MINTEMP/MAXTEMP`. * Overheat protection `ON/OFF/MINTEMP/MAXTEMP`. * Holiday mode `ON/OFF`. * Schedules `ON/OFF`. * Scene `ON/OFF`. * Sensors: * For automation and notifications. * Power `ON/OFF`. * Operating mode `HEAT/DRY/COOL/FAN/AUTO`. * Physical lock controls `LOCK/UNLOCK`. * Vane H mode `AUTO/1/2/3/4/5/SPLIT/SWING`. * Vane V mode `AUTO/1/2/3/4/5/SWING`. * Fan speed mode `AUTO/1/2/3/4/5/`. * Preset `ACTIV/UNACTIV`. * Room temperature. * Outdoor temperature. * Frost protection. * Overheat protection. * Holiday mode. * Shedules control. * Shedule active. * Scene control. * In standby. * Is connected. * Error. * Heat Pump: * Heater Cooler: * Heat Pump: * Power `ON/OFF`. * Operating mode `AUTO/HEAT/COOL` - `POWER OFF/ON/ON`. * Outdoor temperature `GET`. * Physical lock controls all Zones and Hot Water Tank `LOCK/UNLOCK`. * Temperature display unit `°F/°C`. * Zone 1 and 2: * Operating mode heat `AUTO/HEAT/COOL` - `CURVE/HEAT ROOM/HEAT FLOW`. * Operating mode cool `HEAT/COOL` - `FLOOR DRY UP/COOL ROOM/COOL FLOW`. * Temperature `HEATING/COOLING`. * Physical lock controls `LOCK/UNLOCK`. * Hot Water Tank: * Operating mode `AUTO/HEAT` - `AUTO/HEAT NOW`. * Temperature `SET/GET`. * Physical lock controls `LOCK/UNLOCK`. * Thermostat: * Heat Pump: * Power `ON/OFF`. * Operating mode `AUTO/HEAT/COOL` - `POWER OFF/ON/ON`. * Outdoor temperature `GET`. * Temperature display unit `°F/°C`. * Zone 1 and 2: * Operating mode heat `HEAT/COOL/AUTO` - `HEAT ROOM/HEAT FLOW/CURVE`. * Operating mode cool `HEAT/COOL/AUTO` - `COOL ROOM/COOL FLOW/FLOOR DRY UP`. * Temperature `HEATING/COOLING`. * Hot Water Tank: * Operating mode `HEAT/AUTO` - `HEAT NOW, AUTO`. * Temperature `SET/GET`. * Buttons: * For direct device control. * Power `ON/OFF`. * Operating mode `HEAT/COOL/CURVE/HOLIDAY/AUTO HOT WATER/ECO HOT WATER/FORCE HOT WATER`. * Physical lock controls `LOCK/UNLOCK`. * Preset `SET/UNSET`. * Frost protection `ON/OFF/MINTEMP/MAXTEMP`. * Holiday mode `ON/OFF`. * Schedules `ON/OFF`. * Scene `ON/OFF`. * Sensors: * For automation and notifications. * Power `ON/OFF`. * Operating mode `HEAT/COOL/CURVE/HOLIDAY/AUTO HOT WATER/ECO HOT WATER/FORCE HOT WATER`. * Physical lock controls `LOCK/UNLOCK`. * Preset `ACTIV/UNACTIV`. * Outdoor temperature. * Zone 1 temperature. * Zone 2 temperature. * Water tank temperature. * Flow Temperature Zone 1, 2, Hot Water. * Return Temperature Zone 1, 2, Hot Water. * Frost protection. * Holiday mode. * Shedules control. * Shedule active. * Scene control. * In standby. * Is connected. * Error. * Energy Recovery Ventilation Lossnay: * Heater Cooler: * Power `ON/OFF`. * Operating mode `AUTO/HEAT/COOL/POWER OFF` - `AUTO, LOSSNAY, BYPASS, POWER OFF`. * Fan speed `AUTO/1/2/3/4`. * Temperature display unit `°F/°C`. * Thermostat: * Power `ON/OFF`. * Operating mode `POWER OFF/HEAT/COOL/AUTO` - `POWER OFF, LOSSNAY, BYPASS, AUTO`. * Temperature display unit `°F/°C`. * Buttons: * For direct device control. * Power `ON/OFF`. * Operating mode `LOSSNAY/BYPASS/AUTO/NIGHT PURGE`. * Fan speed mode `AUTO/1/2/3/4`. * Preset `SET/UNSET`. * Holiday mode `ON/OFF`. * Schedules `ON/OFF`. * Scene `ON/OFF`. * Sensors: * For automation and notifications. * Power `ON/OFF`. * Operating mode `LOSSNAY/BYPASS/AUTO/NIGHT PURGE`. * Fan speed mode `AUTO/1/2/3/4`. * Presets `ACTIV/UNACTIV`. * Room temperature. * Outdoor temperature. * Supply temperature. * Core maintenance. * Filter maintenance. * CO2 detected and level. * PM2.5 air quality and level. * Holiday mode. * Shedules control. * Shedule active. * Scene control. * In standby. * Is connected. * Error. ### HOME app current device mode display * In AUTO mode, the tile display current state based on current mode: * HEATING mode, th tile display current state as HEATING - orange * COOLING mode, the tile display current state as COOLING - blue * DRY mode, the tile display current state as IDLE - black * FAN mode, the tile display current state as IDLE - black * IDLE mode, the tile display current state as IDLE - black * INACTIVE mode, the tile display current state as INACTIVE - transparent ### AUTO Mode * Heather/Cooler * In this mode we can set heathing threshold and cooling threshold temperature: * Target temperature is calculated as a middle value between `LO` and `HI` and the rest is calculated internally. * Thermostat * In this mode we can set only target temperature: * Target temperature is send to device and calculated internally: * Calculation method in device internally: * If the room temperature `<` Heating Setpoint, the unit will be set to HEAT with a setpoint of 23°C. * In HEAT, if the room temperature `>` Heating Setpoint `+` 1°C, the unit will be set to FAN. * In FAN, if the room temperature `>` Cooling Setpoint, the unit will be set to COOL with a setpoint of 19°C. * In COOL, if the room temperature `<` Cooling Setpoint `-` 1°C, the unit will be set to FAN. * In FAN, if the room temperature `<` Heating Setpoint, the unit will be set to HEAT with a setpoint of 23°C. * The image shows Heating Setpoint of 19°C and a Cooling Setpoint of 23°C.

### Configuration * Run this plugin as a [Child Bridge](https://github.com/homebridge/homebridge/wiki/Child-Bridges) (Highly Recommended), this prevent crash Homebridge if plugin crashes. * Install and use [Homebridge UI](https://github.com/homebridge/homebridge-config-ui-x/wiki) to configure this plugin. * The `sample-config.json` can be edited and used as an alternative.

| Key | Description | | --- | --- | | `name` | Here set the own account name. | | `user` | Here set the account credential (username). | | `passwd` | Here set the account credential (password). | | `language` | Here select the account language. | | `type` | Here select the account type `0 - None / Disabled`, `1 - MELCloud`, `2 - MELCloud Home`. | | `ataDevices[]` | Array of ATA devices created automatically after login to MELCloud from plugin config UI. | | `ataDevices[].id` | Read only data, do not change it. | | `ataDevices[].type` | Read only data, do not change it. | | `ataDevices[].name` | Here set Your own name `Accessory Name` which is exposed to the `Homebridge / HomeKit`. | | `ataDevices[].displayType` | Here select device control mode `0 - None / Disabled`, `1 - Heater / Cooler`, `2 - Thermostat`. | | `ataDevices[].heatDryFanMode` | Here select the operatiing mode for `Heat`, if this mode is not supported, it will be disabled. | | `ataDevices[].coolDryFanMode` | Here select the operatiing mode for `Cool`, if this mode is not supported, it will be disabled. | | `ataDevices[].autoDryFanMode` | Here select the operatiing mode for `Auto`, if this mode is not supported, it will be disabled.. | | `ataDevices[].temperatureSensor` | This enable extra `Room` temperature sensor to use with HomeKit automations. | | `ataDevices[].temperatureOutdoorSensor` | This enable extra `Outdoor` temperature sensor to use with HomeKit automations. | | `ataDevices[].inStandbySensor` | This enable `In Standby Mode` sensor to use with HomeKit automations. | | `ataDevices[].connectSensor` | This enable `Connect State` sensor to use with HomeKit automations. | | `ataDevices[].errorSensor` | This enable `Error` sensor to use with HomeKit automations. | | `ataDevices[].remoteRoomTemperatureSupport` | This enable support to update `Room Temperature` with `MQTT` or `RESTFul`. | | `ataDevices[].frostProtectionSupport` | This enable extra `Frost Protection` control and sensors to use with HomeKit automations. | | `ataDevices[].overheatProtectionSupport` | This enable extra `Overheat Protection` control and sensors to use with HomeKit automations. | | `ataDevices[].holidayModeSupport` | This enable extra `Holiday Mode` control and sensors to use with HomeKit automations. | | `ataDevices[].presets[]` | Array of ATA device `Presets` created automatically after login to MELCloud from plugin config UI. | | `ataDevices[].presets[].id` | Read only data, do not change it. | | `ataDevices[].presets[].name` | Here set Your own name `Preset Name` which is exposed to the `Homebridge / HomeKit`. | | `ataDevices[].presets[].displayType` | Here select display type in HomeKit, `0 - None / Disabled`, `1 - Motion Sensor`, `2 - Occupancy Sensor`, `3 - Contact Sensor`, `4 - Switch + Motion Sensor`, `5 - Switch + Occupancy Sensor`, `6 - Switch + Contact Sensor`, `7 - Switch`. | | `ataDevices[].schedules[]` | Array of ATA device `Schedules` created automatically after login to MELCloud Home from plugin config UI. | | `ataDevices[].schedules[].id` | Read only data, do not change it. | | `ataDevices[].schedules[].name` | Here set Your own name `Schedule Name` which is exposed to the `Homebridge / HomeKit`. | | `ataDevices[].schedules[].displayType` | Here select display type in HomeKit, `0 - None / Disabled`, `1 - Motion Sensor`, `2 - Occupancy Sensor`, `3 - Contact Sensor`, `4 - Switch + Motion Sensor`, `5 - Switch + Occupancy Sensor`, `6 - Switch + Contact Sensor`, `7 - Switch`. | | `ataDevices[].scenes[].id` | Read only data, do not change it. | | `ataDevices[].scenes[].name` | Here set Your own name `Scene Name` which is exposed to the `Homebridge / HomeKit`. | | `ataDevices[].scenes[].displayType` | Here select display type in HomeKit, `0 - None / Disabled`, `1 - Motion Sensor`, `2 - Occupancy Sensor`, `3 - Contact Sensor`, `4 - Switch + Motion Sensor`, `5 - Switch + Occupancy Sensor`, `6 - Switch + Contact Sensor`, `7 - Switch`. | | `ataDevices[].buttonsSensors[]` | Array of buttons sensors. | | `ataDevices[].buttonsSensors[].name` | Here set `Button Name` which You want expose to the `Homebridge / HomeKit`. | | `ataDevices[].buttonsSensors[].mode` | Here select button mode, VH - Vane Horizontal, VV - Vane Horizontal. | | `ataDevices[].buttonsSensors[].displayType` | Here select display type in HomeKit, `0 - None / Disabled`, `1 - Motion Sensor`, `2 - Occupancy Sensor`, `3 - Contact Sensor`, `4 - Switch + Motion Sensor`, `5 - Switch + Occupancy Sensor`, `6 - Switch + Contact Sensor`, `7 - Switch`. | | `ataDevices[].buttonsSensors[].namePrefix` | Here enable the accessory name as a prefix for button / sensor name. | | `atwDevices[]` | Array of ATA devices created automatically after login to MELCloud from plugin config UI. | | `atwDevices[].id` | Read only data, do not change it. | | `atwDevices[].type` | Read only data, do not change it. | | `atwDevices[].name` | Here set Your own name `Accessory Name` which is exposed to the `Homebridge / HomeKit`. | | `atwDevices[].displayType` | Here select main control mode `None / Disabled`, `Heater / Cooler`, `Thermostat`. | | `atwDevices[].hideZone` | Here select which zone need to be hidden `None / Disabled`, `Heat Pump`, `Heat Pump / Zone 1`, `Heat Pump / Zone 1 / Hot Water`, `Heat Pump / Zone 1 / Zone 2`, `Heat Pump / Hot Water`,`Heat Pump / Hot Water / Zone 2`, `Heat Pump / Zone 2`, `Zone 1`, `Zone 1 / Hot Water`, `Zone 1 / Hot Water / Zone 2`, `Zone 1 / Zone 2`, `Hot Water`, `Hot Water / Zone 2`, `Zone 2`, `All`. | | `atwDevices[].temperatureSensor` | This enable extra `Room` temperature sensor to use with HomeKit automations. | | `atwDevices[].temperatureFlowSensor` | This enable extra `Flow` temperature sensor to use with HomeKit automations. | | `atwDevices[].temperatureReturnSensor` | This enable extra `Return` temperature sensor to use with HomeKit automations. | | `atwDevices[].temperatureFlowZone1Sensor` | This enable extra `Flow Zone 1` temperature sensor to use with HomeKit automations. | | `atwDevices[].temperatureReturnZone1Sensor` | This enable extra `Return Zone 1` temperature sensor to use with HomeKit automations. | | `atwDevices[].temperatureFlowWaterTankSensor` | This enable extra `Flow Water Tank` temperature sensor to use with HomeKit automations. | | `atwDevices[].temperatureReturnWaterTankSensor` | This enable extra `Return Water Tank` temperature sensor to use with HomeKit automations. | | `atwDevices[].temperatureFlowZone2Sensor` | This enable extra `Flow Zone 2` temperature sensor to use with HomeKit automations. | | `atwDevices[].temperatureReturnZone2Sensor` | This enable extra `Return Zone 2` temperature sensor to use with HomeKit automations. | | `atwDevices[].inStandbySensor` | This enable `In Standby Mode` sensor to use with HomeKit automations. | | `atwDevices[].connectSensor` | This enable `Connect State` sensor to use with HomeKit automations. | | `atwDevices[].errorSensor` | This enable `Error` sensors to use with HomeKit automations. | | `atwDevices[].holidayModeSupport` | This enable extra `Holiday Mode` control and sensors to use with HomeKit automations. | | `atwDevices[].presets[]` | Array of ATW device `Presets` created automatically after login to MELCloud from plugin config UI. | | `atwDevices[].presets[].id` | Read only data, do not change it. | | `atwDevices[].presets[].name` | Here set Your own name `Preset Name` which is exposed to the `Homebridge/HomeKit`. | | `atwDevices[].presets[].displayType` | Here select display type in HomeKit, `0 - None/Disabled`, `1 - Motion Sensor`, `2 - Occupancy Sensor`, `3 - Contact Sensor`, `4 - Switch + Motion Sensor`, `5 - Switch + Occupancy Sensor`, `6 - Switch + Contact Sensor`, `7 - Switch`. | | `atwDevices[].schedules[]` | Array of ATW device `Schedules` created automatically after login to MELCloud Home from plugin config UI. | | `atwDevices[].schedules[].id` | Read only data, do not change it. | | `atwDevices[].schedules[].name` | Here set Your own name `Schedule Name` which is exposed to the `Homebridge/HomeKit`. | | `atwDevices[].schedules[].displayType` | Here select display type in HomeKit, `0 - None/Disabled`, `1 - Motion Sensor`, `2 - Occupancy Sensor`, `3 - Contact Sensor`, `4 - Switch + Motion Sensor`, `5 - Switch + Occupancy Sensor`, `6 - Switch + Contact Sensor`, `7 - Switch`. | | `atwDevices[].scenes[].id` | Read only data, do not change it. | | `atwDevices[].scenes[].name` | Here set Your own name `Scene Name` which is exposed to the `Homebridge/HomeKit`. | | `atwDevices[].scenes[].displayType` | Here select display type in HomeKit, `0 - None/Disabled`, `1 - Motion Sensor`, `2 - Occupancy Sensor`, `3 - Contact Sensor`, `4 - Switch + Motion Sensor`, `5 - Switch + Occupancy Sensor`, `6 - Switch + Contact Sensor`, `7 - Switch`. | | `atwDevices[].buttonsSensors[]` | Array of buttons sensors. | | `atwDevices[].buttonsSensors[].name` | Here set `Button Name` which You want expose to the `Homebridge / HomeKit`. | | `atwDevices[].buttonsSensors[].mode` | Here select button mode. | | `atwDevices[].buttonsSensors[].displayType` | Here select display type in HomeKit, `0 - None / Disabled`, `1 - Motion Sensor`, `2 - Occupancy Sensor`, `3 - Contact Sensor`, `4 - Switch + Motion Sensor`, `5 - Switch + Occupancy Sensor`, `6 - Switch + Contact Sensor`, `7 - Switch`. | | `atwDevices[].buttonsSensors[].namePrefix` | Here enable the accessory name as a prefix for button / sensor name. | | `ervDevices[]` | Array of ATA devices created automatically after login to MELCloud from plugin config UI. | | `ervDevices[].id` | Read only data, do not change it. | | `ervDevices[].type` | Read only data, do not change it. | | `ervDevices[].name` | Here set Your own name `Accessory Name` which is exposed to the `Homebridge / HomeKit`. | | `ervDevices[].displayType` | Here select main control mode `None / Disabled`, `Heater / Cooler`, `Thermostat`. | | `ervDevices[].temperatureSensor` | This enable extra `Room` temperature sensor to use with HomeKit automations. | | `ervDevices[].temperatureOutdoorSensor` | This enable extra `Outdoor` temperature sensor to use with HomeKit automations. | | `ervDevices[].temperatureSupplySensor` | This enable extra `Supply` temperature sensor to use with HomeKit automations. | | `atwDevices[].inStandbySensor` | This enable `In Standby Mode` sensor to use with HomeKit automations. | | `ervDevices[].connectSensor` | This enable `Connect State` sensor to use with HomeKit automations. | | `ervDevices[].errorSensor` | This enable `Error` sensors to use with HomeKit automations. | | `ervDevices[].holidayModeSupport` | This enable extra `Holiday Mode` control and sensors to use with HomeKit automations. | | `ervDevices[].presets[]` | Array of ERV device `Presets` created automatically after login to MELCloud from plugin config UI. | | `ervDevices[].presets[].id` | Read only data, do not change it. | | `ervDevices[].presets[].name` | Here set Your own name `Preset Name` which is exposed to the `Homebridge / HomeKit`. | | `ervDevices[].presets[].displayType` | Here select display type in HomeKit, `0 - None / Disabled`, `1 - Motion Sensor`, `2 - Occupancy Sensor`, `3 - Contact Sensor`, `4 - Switch + Motion Sensor`, `5 - Switch + Occupancy Sensor`, `6 - Switch + Contact Sensor`, `7 - Switch`. | | `ervDevices[].schedules[]` | Array of ERV device `Schedules` created automatically after login to MELCloud Home from plugin config UI. | | `ervDevices[].schedules[].id` | Read only data, do not change it. | | `ervDevices[].schedules[].name` | Here set Your own name `Schedule Name` which is exposed to the `Homebridge / HomeKit`. | | `ervDevices[].schedules[].displayType` | Here select display type in HomeKit, `0 - None / Disabled`, `1 - Motion Sensor`, `2 - Occupancy Sensor`, `3 - Contact Sensor`, `4 - Switch + Motion Sensor`, `5 - Switch + Occupancy Sensor`, `6 - Switch + Contact Sensor`, `7 - Switch`. | | `ervDevices[].scenes[].id` | Read only data, do not change it. | | `ervDevices[].scenes[].name` | Here set Your own name `Scene Name` which is exposed to the `Homebridge / HomeKit`. | | `ervDevices[].scenes[].displayType` | Here select display type in HomeKit, `0 - None / Disabled`, `1 - Motion Sensor`, `2 - Occupancy Sensor`, `3 - Contact Sensor`, `4 - Switch + Motion Sensor`, `5 - Switch + Occupancy Sensor`, `6 - Switch + Contact Sensor`, `7 - Switch`. | | `ervDevices[].buttonsSensors[]` | Array of buttons sensors. | | `ervDevices[].buttonsSensors[].name` | Here set `Button Name` which You want expose to the `Homebridge / HomeKit`. | | `ervDevices[].buttonsSensors[].mode` | Here select button mode. | | `ervDevices[].buttonsSensors[].displayType` | Here select display type in HomeKit, `0 - None / Disabled`, `1 - Motion Sensor`, `2 - Occupancy Sensor`, `3 - Contact Sensor`, `4 - Switch + Motion Sensor`, `5 - Switch + Occupancy Sensor`, `6 - Switch + Contact Sensor`, `7 - Switch`. | | `ervDevices[].buttonsSensors[].namePrefix` | Here enable the accessory name as a prefix for button / sensor name. | | `refreshInterval` | Here set the background account data refresh time in (sec) , only for old MELCLoud, default `120s`. | | `log{}` | Log object. | | `log.deviceInfo` | This enable log device info will be displayed by every connections device to the network. | | `log.success` | This enable success log will be displayed in console. | | `log.info` | This enable info log will be displayed in console. | | `log.warn` | This enable warn log will be displayed in console. | | `log.error` | This enable error log will be displayed in console. | | `log.debug` | This enable debug log will be displayed in console. | | `restFul{}` | RSTful object. | | `restFul.enable` | This enable RESTful server will start automatically and respond to any path request. | | `mqtt{}` | MQTT object. | | `mqtt.enable` | This enable MQTT Broker will start automatically and publish all awailable PV data. | | `mqtt.host` | Here set the `IP Address` or `Hostname` for MQTT Broker. | | `mqtt.port` | Here set the `Port` for MQTT Broker, default 1883. | | `mqtt.clientId` | Here optional set the `Client Id` of MQTT Broker. | | `mqtt.prefix` | Here set the `Prefix` for `Topic` or leave empty. | | `mqtt.auth{}` | MQTT authorization object. | | `mqtt.auth.enable` | Here enable authorization for MQTT Broker. | | `mqtt.auth.user` | Here set the MQTT Broker user. | | `mqtt.auth.passwd` | Here set the MQTT Broker password. | ### RESTful Integration * Port: * MELCLoud, last 4 numbers of `device Id`, correct port is displayed in HB log during start. * MELCLoud Home, start at `30000`, correct port is displayed in HB log during start. * POST data as a JSON Object `{OperationMode: 8}`. * Header content type must be `application/json`. * Path `status` response all available paths. | Method | URL | Path | Response | Type | | --- | --- | --- | --- | --- | | GET | `http//ip:port` | `info`, `state` | `{"Power": true, "SetTemperature": 21.5}` | JSON object. | | Method | URL | Key | Value | Type | Description | | --- | --- | --- | --- | --- | --- | | Air Conditioner | | | | | | | POST | `http//ip:port` | `Power` | `true`, `false` | boolean | Power state. | | | `http//ip:port` | `ProhibitSetTemperature` | `true`, `false` | boolean | Lock set temperature (Only MELCloud). | | | `http//ip:port` | `ProhibitOperationMode` | `true`, `false` | boolean | Lock set operating mode (Only MELCloud). | | | `http//ip:port` | `ProhibitPower` | `true`, `false` | boolean | Lock set power (Only MELCloud). | | | `http//ip:port` | `OperationMode` | `1 - Heat`, `2 - Dry`, `3 - Cool`, `7 - Fan`, `8 - Auto` | integer | Operating mode. | | | `http//ip:port` | `FanSpeed` | `0 - Auto`, `1`, `2`, `3`, `4`, `5`, `6` | integer | Fan speed. | | | `http//ip:port` | `VaneHorizontalDirection` | `0`, `1`, `2`, `3`, `4`, `5`, `8 - Split`, `12 - Swing` | integer | Vane H mode. | | | `http//ip:port` | `VaneVerticalDirection` | `0`, `1`, `2`, `3`, `4`, `5`, `7 - Swing` | integer | Vane V mode. | | | `http//ip:port` | `SetTemperature` | `0.0` | float | Room temperature. | | | `http//ip:port` | `DefaultCoolingSetTemperature` | `0.0` | float | Default cooling temperature. | | | `http//ip:port` | `DefaultHeatingSetTemperature` | `0.0` | float | Default heating temperature. | | | `http//ip:port` | `FrostProtection` | `true`, `false` | boolean | Frost protectin (Only MELCloud Home). | | | `http//ip:port` | `OverheatProtection` | `true`, `false` | boolean | Overheat protection (Only MELCloud Home). | | | `http//ip:port` | `Schedules` | `true`, `false` | boolean | Schedules (Only MELCloud Home). | | | `http//ip:port` | `HolidayMode` | `true`, `false` | boolean | Holiday mode. | | | `http//ip:port` | `RemoteRoomTemperature` | `23.0` | float | Remote room temperature. | | Heat Pump | | | | | | | POST | `http//ip:port` | `Power` | `true`, `false` | boolean | Power state. | | | `http//ip:port` | `OperationModeZone1` | `0 - Heat Room`, `1 - Heat Flow`, `2 - Heat Curve`, `3 - Cool Room`, `4 - Cool Flow`, `5 - Flor Dry Up` | integer | Operating mode zone 1. | | | `http//ip:port` | `SetTemperatureZone1` | `0.0` | float | Temperature zone 1. | | | `http//ip:port` | `SetHeatFlowTemperatureZone1` | `0.0` | float | Heat flow temperature zone 1. | | | `http//ip:port` | `SetCoolFlowTemperatureZone1` | `0.0` | float | Cool flow temperature zone 1. | | | `http//ip:port` | `ProhibitZone1` | `true`, `false` | boolean | Lock control zone 1 (Only MELCloud). | | | `http//ip:port` | `ForcedHotWaterMode` | `true`, `false` | boolean | Force hot water. | | | `http//ip:port` | `EcoHotWater` | `true`, `false` | boolean | Eco hot water (Only MELCloud). | | | `http//ip:port` | `SetTankWaterTemperature` | `0.0` | float | Hot water temperature. | | | `http//ip:port` | `ProhibitHotWater` | `true`, `false` | boolean | Lock control hot water. | | | `http//ip:port` | `OperationModeZone2` | `0 - Heat Room`, `1 - Heat Flow`, `2 - Heat Curve`, `3 - Cool Room`, `4 - Cool Flow`, `5 - Flor Dry Up` | integer | Operating mode zone 2. | | | `http//ip:port` | `SetTemperatureZone2` | `0.0` | float | Temperature zone 2. | | | `http//ip:port` | `SetHeatFlowTemperatureZone2` | `0.0` | float | Heat flow temperature zone 2. | | | `http//ip:port` | `SetCoolFlowTemperatureZone2` | `0.0` | float | Cool flow temperature zone 2. | | | `http//ip:port` | `ProhibitZone2` | `true`, `false` | boolean | Lock control zone 2 (Only MELCloud). | | | `http//ip:port` | `FrostProtection` | `true`, `false` | boolean | Frost protectin (Only MELCloud Home). | | | `http//ip:port` | `Schedules` | `true`, `false` | boolean | Schedules (Only MELCloud Home). | | | `http//ip:port` | `HolidayMode` | `true`, `false` | boolean | Holiday mode. | | Energy Recovery Ventilation | | | | | | | POST | `http//ip:port` | `Power` | `true`, `false` | boolean | Power state. | | | `http//ip:port` | `NightPurgeMode` | `true`, `false` | boolean | Night purge mode. | | | `http//ip:port` | `OperationMode` | `1 - Heat`, `3 - Cool`, `7 - Fan`, `8 - Auto` | integer | Operating mode. | | | `http//ip:port` | `VentilationMode` | `0 - Lossnay`, `1 - Bypass`, `2 - Auto` | integer | Ventilation mode. | | | `http//ip:port` | `SetFanSpeed` | `0 - Auto`, `1`, `2`, `3`, `4` | integer | Fan speed. | | | `http//ip:port` | `SetTemperature` | `0.0` | float | Room temperature. | | | `http//ip:port` | `DefaultCoolingSetTemperature` | `0.0` | float | Default cooling temperature. | | | `http//ip:port` | `DefaultHeatingSetTemperature` | `0.0` | float | Default heating temperature. | | | `http//ip:port` | `Schedules` | `true`, `false` | boolean | Schedules (Only MELCloud Home). | | | `http//ip:port` | `HolidayMode` | `true`, `false` | boolean | Holiday mode. | ### MQTT Integration * Subscribe data as a JSON Object `{"Power": true}` | Direction | Topic | Message | Type | | --- | --- | --- | --- | | Publish | `Info`, `State` | `{"Power": true, "SetTemperature": 21.5}` | JSON object. | | Method | Topic | Key | Value | Type | Description | | --- | --- | --- | --- | --- | --- | | Air Conditioner | | | | | | | Subscribe | `Set` | `Power` | `true`, `false` | boolean | Power state. | | | `Set` | `ProhibitSetTemperature` | `true`, `false` | boolean | Lock set temperature (Only MELCloud). | | | `Set` | `ProhibitOperationMode` | `true`, `false` | boolean | Lock set operating mode (Only MELCloud). | | | `Set` | `ProhibitPower` | `true`, `false` | boolean | Lock set power (Only MELCloud). | | | `Set` | `OperationMode` | `1 - Heat`, `2 - Dry`, `3 - Cool`, `7 - Fan`, `8 - Auto` | integer | Operating mode. | | | `Set` | `FanSpeed` | `0 - Auto`, `1`, `2`, `3`, `4`, `5`, `6` | integer | Fan speed. | | | `Set` | `VaneHorizontalDirection` | `0`, `1`, `2`, `3`, `4`, `5`, `8 - Split`, `12 - Swing` | integer | Vane H mode. | | | `Set` | `VaneVerticalDirection` | `0`, `1`, `2`, `3`, `4`, `5`, `7 - Swing` | integer | Vane V mode. | | | `Set` | `SetTemperature` | `0.0` | float | Room temperature. | | | `Set` | `DefaultCoolingSetTemperature` | `23.0` | float | Default cooling temperature. | | | `Set` | `DefaultHeatingSetTemperature` | `21.0` | float | Default heating temperature. | | | `Set` | `FrostProtection` | `true`, `false` | boolean | Frost protectin (Only MELCloud Home). | | | `Set` | `OverheatProtection` | `true`, `false` | boolean | Overheat protection (Only MELCloud Home). | | | `Set` | `Schedules` | `true`, `false` | boolean | Schedules (Only MELCloud Home). | | | `Set` | `HolidayMode` | `true`, `false` | boolean | Holiday mode. | | | `Set` | `RemoteRoomTemperature` | `23.0` | float | Remote room temperature. | | Heat Pump | | | | | | | Subscribe | `Set` | `Power` | `true`, `false` | boolean | Power state. | | | `Set` | `OperationModeZone1` | `0 - Heat Room`, `1 - Heat Flow`, `2 - Heat Curve`, `3 - Cool Room`, `4 - Cool Flow`, `5 - Flor Dry Up` | integer | Operating mode zone 1. | | | `Set` | `SetTemperatureZone1` | `0.0` | float | Temperature zone 1. | | | `Set` | `SetHeatFlowTemperatureZone1` | `0.0` | float | Heat flow temperature zone 1. | | | `Set` | `SetCoolFlowTemperatureZone1` | `0.0` | float | Cool flow temperature zone 1. | | | `Set` | `ProhibitZone1` | `true`, `false` | boolean | Lock control zone 1 (Only MELCloud). | | | `Set` | `ForcedHotWaterMode` | `true`, `false` | boolean | Force hot water. | | | `Set` | `EcoHotWater` | `true`, `false` | boolean | Eco hot water (Only MELCloud). | | | `Set` | `SetTankWaterTemperature` | `0.0` | float | Hot water temperature. | | | `Set` | `ProhibitHotWater` | `true`, `false` | boolean | Lock control hot water. | | | `Set` | `OperationModeZone2` | `0 - Heat Room`, `1 - Heat Flow`, `2 - Heat Curve`, `3 - Cool Room`, `4 - Cool Flow`, `5 - Flor Dry Up` | integer | Operating mode zone 2. | | | `Set` | `SetTemperatureZone2` | `0.0` | float | Temperature zone 2. | | | `Set` | `SetHeatFlowTemperatureZone2` | `0.0` | float | Heat flow temperature zone 2. | | | `Set` | `SetCoolFlowTemperatureZone2` | `0.0` | float | Cool flow temperature zone 2. | | | `Set` | `ProhibitZone2` | `true`, `false` | boolean | Lock control zone 2 (Only MELCloud). | | | `Set` | `FrostProtection` | `true`, `false` | boolean | Frost protectin (Only MELCloud Home). | | | `Set` | `Schedules` | `true`, `false` | boolean | Schedules (Only MELCloud Home). | | | `Set` | `HolidayMode` | `true`, `false` | boolean | Holiday mode. | | Energy Recovery Ventilation | | | | | | | Subscribe | `Set` | `Power` | `true`, `false` | boolean | Power state. | | | `Set` | `NightPurgeMode` | `true`, `false` | boolean | Night purge mode. | | | `Set` | `OperationMode` | `1 - Heat`, `3 - Cool`, `7 - Fan`, `8 - Auto` | integer | Operating mode. | | | `Set` | `VentilationMode` | `0 - Lossnay`, `1 - Bypass`, `2 - Auto` | integer | Ventilation mode. | | | `Set` | `SetFanSpeed` | `0 - Auto`, `1`, `2`, `3`, `4` | integer | Fan speed. | | | `Set` | `SetTemperature` | `0.0` | float | Room temperature. | | | `Set` | `DefaultCoolingSetTemperature` | `23.0` | float | Default cooling temperature. | | | `Set` | `DefaultHeatingSetTemperature` | `21.0` | float | Default heating temperature. | | | `Set` | `Schedules` | `true`, `false` | boolean | Schedules (Only MELCloud Home). | | | `Set` | `HolidayMode` | `true`, `false` | boolean | Holiday mode. |
