pilotty
The terminal equivalent of agent-browser
Terminal automation CLI for AI agents
Control vim, htop, lazygit, dialog, and any TUI programmatically
Installation •
Quick Start •
Commands •
AI Agents
---
> [!NOTE]
> **Built with AI, for AI.** This project was built with the support of an AI agent, planned thoroughly with a tight feedback loop and reviewed at each step. While we've tested extensively, edge cases may exist. Use in production at your own discretion, and please [report any issues](https://github.com/msmps/pilotty/issues) you find!
pilotty enables AI agents to interact with terminal applications through a simple command-line interface. It manages pseudo-terminal (PTY) sessions with full VT100 terminal emulation, captures screen state, and provides keyboard/mouse input for navigating terminal user interfaces. Think of it as headless terminal automation for AI workflows.
## Features
- **PTY (Pseudo-Terminal) Management**: Spawn and manage terminal applications in background sessions
- **Terminal Emulation**: Full VT100 emulation for accurate screen capture and state tracking
- **Keyboard Navigation**: Interact with TUIs using Tab, Enter, arrow keys, and key combos
- **AI-Friendly Output**: Clean JSON responses with actionable suggestions on errors
- **Multi-Session**: Run multiple terminal apps simultaneously in isolated sessions
- **Zero Config**: Daemon auto-starts on first command, auto-stops after 5 minutes idle
## Why pilotty?
[agent-browser](https://github.com/vercel-labs/agent-browser) by Vercel Labs lets AI agents control web browsers. pilotty does the same for terminals.
**Origin story:** Built to solve a personal problem, pilotty was created to enable AI agents to interact with [OpenTUI](https://github.com/anomalyco/opentui) interfaces and control [OpenCode](https://github.com/anomalyco/opencode) programmatically. If you're building TUIs or working with terminal applications, pilotty lets AI navigate them just like a human would.
## Installation
### npm (recommended)
```bash
npm install -g pilotty
```
### From Source
```bash
git clone https://github.com/msmps/pilotty
cd pilotty
cargo build --release
./target/release/pilotty --help
```
Requires [Rust](https://rustup.rs) 1.70+.
## Platform Support
| Platform | Architecture | Status |
|----------|--------------|--------|
| macOS | x64 (Intel) | ✅ |
| macOS | arm64 (Apple Silicon) | ✅ |
| Linux | x64 | ✅ |
| Linux | arm64 | ✅ |
| Windows | - | ❌ Not supported |
Windows is not supported due to the use of Unix domain sockets and POSIX PTY APIs.
## Quick Start
```bash
# Spawn a TUI application
pilotty spawn htop
# Take a snapshot of the terminal
pilotty snapshot
# Type text
pilotty type "hello world"
# Send keys
pilotty key Enter
pilotty key Ctrl+C
# Click at specific coordinates (row, col)
pilotty click 10 5
# List active sessions
pilotty list-sessions
# Stop the daemon
pilotty stop
```
## Commands
### Session Management
```bash
pilotty spawn # Spawn a TUI app (e.g., pilotty spawn vim file.txt)
pilotty spawn --name myapp # Spawn with a custom session name
pilotty spawn --cwd /path cmd # Spawn in a specific working directory
pilotty spawn --retain-bytes 1048576 # Override retained output limit
pilotty kill # Kill default session
pilotty kill -s myapp # Kill specific session
pilotty list-sessions # List all active sessions
pilotty status # Report default session lifecycle status
pilotty status -s myapp # Report a named session's status
pilotty stop # Stop the daemon and all sessions
pilotty daemon # Manually start daemon (usually auto-starts)
pilotty examples # Show end-to-end workflow example
```
### Retained Output
```bash
pilotty output # Readable retained output from the default session
pilotty output -s myapp # Readable retained output from a named session
pilotty output -s myapp --ansi > output.ansi # Save exact retained ANSI/VT bytes
```
`output` replays the bounded retained byte window into a readable terminal-history tail.
`--ansi` writes the exact retained bytes instead. Both modes report exact raw-byte
retention accounting to stderr, including when older bytes were dropped. Retention is
bounded to 2 MiB per session by default.
When a session exits, the daemon keeps bounded final evidence in memory for up to 10
minutes: exit metadata, the final full screen, and the last 64 KiB of raw output.
`snapshot` and `output` continue to work during that window. Commands that require a live
process return `SESSION_EXITED`. Tombstones disappear when they expire, are evicted, or
the daemon restarts, and never keep the daemon running.
### Session Status
```bash
pilotty status # Status of the default session
pilotty status -s myapp # Status by session name or ID
```
`status` returns structured JSON with `state: "running"` or `state: "exited"`.
Running sessions include their current geometry, command, working directory, creation
time, idle duration, and retention accounting. Exited sessions include final geometry,
exit code or signal, success and explicit-kill flags, creation and end times, output
completeness, and retained-evidence accounting. Unknown, expired, or evicted sessions
return `SESSION_NOT_FOUND`.
### Screen Capture
```bash
pilotty snapshot # Full JSON with text
pilotty snapshot --format compact # JSON without text field
pilotty snapshot --format text # Plain text with cursor indicator
# Wait for screen to change before returning (no more manual sleep!)
pilotty snapshot --await-change $HASH # Block until hash differs
pilotty snapshot --await-change $HASH --settle 100 # Then wait for stability
pilotty snapshot --settle 100 --strict # Fail on deadline or session exit
```
### Input
```bash
pilotty type "hello" # Type text at cursor
pilotty key Enter # Send Enter key
pilotty key Ctrl+C # Send Ctrl+C
pilotty key Alt+F # Send Alt+F
pilotty key F1 # Send function key
pilotty key Tab # Send Tab
pilotty key Escape # Send Escape
# Key sequences (space-separated keys sent in order)
pilotty key "Ctrl+X m" # Emacs chord: Ctrl+X then m
pilotty key "Escape : w q Enter" # vim :wq sequence
pilotty key "a b c" --delay 50 # Send a, b, c with 50ms delay between
```
### Interaction
```bash
pilotty click 10 5 # Click at row 10, col 5
pilotty scroll up # Scroll up 1 line
pilotty scroll down 5 # Scroll down 5 lines
```
### Terminal Control
```bash
pilotty resize 120 40 # Resize terminal to 120x40
pilotty wait-for "Ready" # Wait for text to appear
pilotty wait-for "Error" --regex # Wait for regex pattern
pilotty wait-for "Done" -t 5000 # Wait with 5s timeout
# Wait for screen changes (preferred over sleep)
HASH=$(pilotty snapshot | jq '.content_hash')
pilotty key Enter
pilotty snapshot --await-change $HASH --settle 50 # Wait for change + 50ms stability
```
## Snapshot Output
The `snapshot` command returns structured data about the terminal screen:
```json
{
"outcome": "immediate",
"size": { "cols": 80, "rows": 24 },
"cursor": { "row": 5, "col": 10, "visible": true },
"text": "Options: [x] Enable [ ] Debug\nActions: [OK] [Cancel]",
"content_hash": 12345678901234567890
}
```
JSON snapshots always include an `outcome`: `immediate`, `changed`, `settled`,
`deadline`, or `exited`. Deadline and exit outcomes return the latest available screen evidence
instead of replacing it with an error. Exited captures include process exit metadata and
whether the final output was completely drained.
### Wait for Screen Changes
The `--await-change` flag solves the fundamental problem of TUI automation: **"How long should I wait after an action?"**
Instead of guessing sleep durations (too short = race condition, too long = slow), wait for the screen to actually change:
```bash
# Capture baseline hash
HASH=$(pilotty snapshot | jq '.content_hash')
# Perform action
pilotty key Enter
# Wait for screen to change (blocks until hash differs)
pilotty snapshot --await-change $HASH
# Or wait for screen to stabilize (useful for apps that render progressively)
pilotty snapshot --await-change $HASH --settle 100 # Wait 100ms after last change
```
**Flags:**
- `--await-change `: Block until `content_hash` differs from this value
- `--settle `: After change detected, wait for screen to be stable for this many ms
- `-t, --timeout `: Maximum wait time (default: 30000)
- `--strict`: Preserve printed evidence but exit 3 on deadline or 4 on session exit
Without `--strict`, every capture outcome exits 0. CLI exit categories are: 0
success, 1 generic/API error, 2 command-line usage, 3 timing deadline, and 4 session
lifecycle. Commands that require a live process also exit 4 when they receive
`SESSION_EXITED`.
**Why this matters:**
- No more flaky automation due to race conditions
- No more slow scripts due to conservative sleep values
- Works regardless of how fast/slow the target app is
- The `--settle` flag handles apps that render progressively
### Streaming AI Responses
For AI-powered TUIs that stream responses (opencode, etc.), use longer settle times:
```bash
HASH=$(pilotty snapshot -s ai | jq -r '.content_hash')
pilotty type -s ai "explain this code"
pilotty key -s ai Enter
# Wait for streaming to complete: 3s settle, 60s timeout
pilotty snapshot -s ai --await-change "$HASH" --settle 3000 -t 60000
```
- Use `--settle 2000-3000` because AI responses pause between chunks
- Extend timeout with `-t 60000` for longer generations
- Long responses may scroll; use `pilotty scroll up` to see the full output
### Manual Change Detection
For manual polling, use `content_hash` directly:
```bash
# Get initial snapshot
SNAP1=$(pilotty snapshot)
HASH1=$(echo "$SNAP1" | jq -r '.content_hash')
# Perform some action
pilotty key Tab
# Check if screen changed
SNAP2=$(pilotty snapshot)
HASH2=$(echo "$SNAP2" | jq -r '.content_hash')
if [ "$HASH1" != "$HASH2" ]; then
echo "Screen content changed"
fi
```
### Workflow Example
```bash
# 1. Spawn a dialog
pilotty spawn dialog --yesno "Continue?" 10 40
# 2. Wait for dialog to render
pilotty wait-for "Continue"
# 3. Inspect the visible screen
pilotty snapshot --format text
# 4. Navigate and interact with keyboard
pilotty key Tab # Move to the next control
pilotty key Enter # Activate the selected control
```
## Sessions
Each session is an isolated terminal with its own:
- PTY (pseudo-terminal)
- Screen buffer
- Child process
```bash
# Run multiple apps (--name must come before the command)
pilotty spawn --name monitoring htop
pilotty spawn --name editor vim file.txt
# Run app in a specific directory (useful for project-specific configs)
pilotty spawn --cwd /path/to/project --name myapp bun src/index.tsx
# Target specific session
pilotty snapshot -s monitoring
pilotty key -s editor Ctrl+S
# List all sessions
pilotty list-sessions
```
If no `--session` is specified, pilotty uses the default session.
Note: The first session spawned without `--name` is automatically named `default`.
To run multiple sessions, give each a unique name with `--name`:
```bash
pilotty spawn --name monitoring htop
pilotty spawn --name editor vim
```
> **Important:** The `--name` flag must come **before** the command. Everything after the command is passed as arguments to that command.
## Daemon Architecture
pilotty uses a daemon architecture similar to agent-browser:
```
┌─────────────┐ Unix Socket ┌─────────────────┐
│ CLI │ ──────────────────▶ │ Daemon │
│ (pilotty) │ JSON-line │ (auto-started) │
└─────────────┘ └─────────────────┘
│
┌────────┴────────┐
▼ ▼
┌───────────┐ ┌───────────┐
│ Session │ │ Session │
│ (htop) │ │ (vim) │
└───────────┘ └───────────┘
```
- **Auto-start**: Daemon starts automatically on first command
- **Auto-stop**: Daemon shuts down after 5 minutes with no active sessions
- **Session cleanup**: Sessions are automatically removed when their process exits
- **Background**: Runs in background, survives terminal close
- **Shared state**: Multiple CLI invocations share sessions
- **Clean shutdown**: `pilotty stop` gracefully terminates all sessions
### Lifecycle
The daemon is designed for zero-maintenance operation:
1. **First command** (e.g., `pilotty spawn vim`) starts the daemon automatically
2. **Session ends** (e.g., vim exits after `:wq`) and the session is cleaned up within 500ms
3. **Idle timeout**: After 5 minutes with no sessions, the daemon shuts down
4. **Next command** starts the daemon again automatically
This means you never need to manually manage the daemon, it starts when needed and stops when idle.
### Socket Location
The daemon socket is created at (in priority order):
1. `$PILOTTY_SOCKET_DIR/{session}.sock` (explicit override)
2. `$XDG_RUNTIME_DIR/pilotty/{session}.sock` (Linux standard)
3. `~/.pilotty/{session}.sock` (home directory fallback)
4. `/tmp/pilotty/{session}.sock` (last resort)
## Error Handling
All errors include AI-friendly suggestions:
```json
{
"code": "SESSION_NOT_FOUND",
"message": "Session 'abc123' not found",
"suggestion": "Run 'pilotty list-sessions' to see available sessions"
}
```
## Environment Variables
| Variable | Description |
|----------|-------------|
| `PILOTTY_SESSION` | Default session name |
| `PILOTTY_SOCKET_DIR` | Override socket directory |
| `PILOTTY_RETAIN_BYTES` | Default retained raw output bytes per session (default: 2 MiB) |
| `RUST_LOG` | Logging level (e.g., `debug`, `info`) |
## Usage with AI Agents
### AI Coding Assistants
Add the skill to your AI coding assistant for richer context:
```bash
npx skills add msmps/pilotty
```
This works with Claude Code, Codex, Cursor, Gemini CLI, GitHub Copilot, Goose, OpenCode, and Windsurf.
### Just Ask the Agent
The simplest approach - just tell your agent to use it:
```
Use pilotty to interact with vim. Run pilotty --help to see available commands.
```
The `--help` output is comprehensive and most agents can figure it out from there.
### AGENTS.md / CLAUDE.md
For more consistent results, add to your project or global instructions file:
```markdown
## Terminal Automation
Use `pilotty` for TUI automation. Run `pilotty --help` for all commands.
Core workflow:
1. `pilotty spawn ` - Start a TUI application
2. `pilotty snapshot` - Get screen state with cursor position
3. `pilotty key Tab` / `pilotty type "text"` - Navigate and interact
4. Re-snapshot after screen changes
```
### Example Workflow
```bash
# 1. Spawn the application
pilotty spawn vim myfile.txt
# 2. Wait for it to be ready
pilotty wait-for "myfile.txt"
# 3. Take a snapshot to understand the screen and capture hash
HASH=$(pilotty snapshot | jq '.content_hash')
# 4. Navigate using keyboard commands
pilotty key i # Enter insert mode
pilotty type "Hello, World!"
pilotty key Escape
# 5. Wait for screen to update, then save (no manual sleep needed!)
pilotty snapshot --await-change $HASH --settle 50
pilotty key "Escape : w q Enter" # vim :wq sequence
# 6. Verify vim exited
pilotty list-sessions
```
### Example: AI TUI Interaction
For AI-powered terminal apps that stream responses:
```bash
# 1. Spawn the AI app
pilotty spawn --name ai opencode
# 2. Wait for prompt
pilotty wait-for -s ai "Ask anything" -t 15000
# 3. Capture baseline hash, type prompt, submit
HASH=$(pilotty snapshot -s ai | jq -r '.content_hash')
pilotty type -s ai "write a haiku about rust"
pilotty key -s ai Enter
# 4. Wait for streaming response (3s settle, 60s timeout)
pilotty snapshot -s ai --await-change "$HASH" --settle 3000 -t 60000 --format text
# 5. Scroll up if response is long
pilotty scroll -s ai up 10
pilotty snapshot -s ai --format text
# 6. Clean up
pilotty kill -s ai
```
## Key Combinations
Supported key formats:
| Format | Example | Notes |
|--------|---------|-------|
| Named keys | `Enter`, `Tab`, `Escape`, `Space`, `Backspace` | Case insensitive |
| Arrow keys | `Up`, `Down`, `Left`, `Right` | Also: `ArrowUp`, etc. |
| Navigation | `Home`, `End`, `PageUp`, `PageDown`, `Insert`, `Delete` | Also: `PgUp`, `PgDn`, `Ins`, `Del` |
| Function keys | `F1` - `F12` | |
| Ctrl combos | `Ctrl+C`, `Ctrl+X`, `Ctrl+Z` | Also: `Control+C` |
| Alt combos | `Alt+F`, `Alt+X` | Also: `Meta+F`, `Option+F` |
| Shift combos | `Shift+A` | Only uppercases letter keys |
| Combined | `Ctrl+Alt+C` | |
| Special | `Plus` | Literal `+` character |
| Aliases | `Return` = `Enter`, `Esc` = `Escape` | |
| **Sequences** | `"Ctrl+X m"`, `"Escape : w q Enter"` | Space-separated keys |
### Key Sequences
Send multiple keys in order with optional delay between them:
```bash
# Emacs-style chords
pilotty key "Ctrl+X Ctrl+S" # Save in Emacs
pilotty key "Ctrl+X m" # Compose mail in Emacs
# vim command sequences
pilotty key "Escape : w q Enter" # Save and quit vim
pilotty key "g g d G" # Delete entire file in vim
# With inter-key delay (useful for slow TUIs)
pilotty key "Tab Tab Enter" --delay 100 # Navigate with 100ms between keys
```
The `--delay` flag specifies milliseconds between keys (max 10000ms, default 0).
## Contributing
Contributions welcome! Please:
1. Run `cargo fmt` before committing
2. Run `cargo clippy --all --all-features` and fix warnings
3. Add tests for new functionality
4. Update documentation as needed
## License
MIT
## Acknowledgments
- Inspired by [agent-browser](https://github.com/vercel-labs/agent-browser) by Vercel Labs
- Built with [vt100](https://crates.io/crates/vt100) for terminal emulation
- Built with [portable-pty](https://crates.io/crates/portable-pty) for PTY management
