Heddle
The policy-and-trust layer for MCP tool servers.
Heddle turns declarative configs into Model Context Protocol servers
with trust enforcement, credential brokering, and tamper-evident audit logging built in.
See It Work ·
Why Heddle ·
Current Status ·
Security ·
Quick Start
---
See It Work
**One config, one MCP server.** This YAML is a complete tool server — no Python, no boilerplate:
```yaml
agent:
name: prometheus-bridge
version: "1.0.0"
description: "Bridges Prometheus for natural language metric queries"
exposes:
- name: query_prometheus
description: "Run a PromQL query"
parameters:
query: { type: string, required: true }
- name: get_alerts
description: "List active Prometheus alerts"
http_bridge:
- tool_name: query_prometheus
method: GET
url: "http://localhost:9090/api/v1/query"
query_params: { query: query }
- tool_name: get_alerts
method: GET
url: "http://localhost:9090/api/v1/alerts"
runtime:
trust_tier: 1 # enforced: GET/HEAD only, no writes, no cross-agent calls
```
Run it:
```bash
heddle run agents/prometheus-bridge.yaml
```
Claude can now query Prometheus in natural language.
**Current demo environment:** 46 tools from 9 active configs through a single MCP connection (11 configs total, 2 excluded for incompatible transports).
```text
daily-ops (T3): daily_briefing, system_health_check, threat_landscape
gitea-api-bridge (T1): list_user_repos, list_repo_issues
grafana-bridge (T1): list_dashboards, get_dashboard, list_datasources, get_alert_rules, grafana_health
ai-platform (T1): health, ai_status, routing_stats, routing_costs, list_apps, detect_drift, ...
ollama-bridge (T2): list_models, list_running, generate, show_model
prometheus-bridge(T1): query_prometheus, query_range, get_targets, get_alerts, get_metric_names
rsshub-bridge (T1): get_hacker_news, get_github_trending, search_arxiv, get_reuters_news
vram-orchestrator(T3): vram_status, smart_load, smart_generate, optimize_vram, unload_model, model_library, ...
intel-rag-bridge (T2): ask_intel, get_dossier, get_trending, get_patterns, get_communities, get_stats, ...
```
**Security is always on.** Every tool call passes through trust enforcement, credential brokering, and audit logging.
Example: a T1 (read-only) agent attempted a POST and was blocked:
```json
{
"event": "trust_violation",
"agent": "reader",
"trust_tier": 1,
"action": "http_POST",
"detail": "T1 agent cannot use POST. Allowed: ['GET', 'HEAD', 'OPTIONS']",
"severity": "high",
"chain_hash": "92c189e3..."
}
```
The request was rejected, the violation was logged, and the hash chain links this entry to every event before and after it.
---
Why Heddle Instead Of...
| | **Heddle** | **Hand-written FastMCP** | **OpenAPI wrapper gen** | **n8n / workflow tools** |
|:--:|:--:|:--:|:--:|:--:|
| **New tool** | Write YAML, done | Write Python handler per tool | Generate stubs, then customize | Drag nodes, wire connections |
| **Security** | Trust tiers, credential broker, input validation, config signing, anomaly detection — all built in | You build it yourself | None | Platform-level auth only |
| **Isolation** | Docker sandboxing: `--cap-drop=ALL`, read-only root, pids limit, image digest pinning, watchdog | Process-level only | None | None |
| **AI-generatable** | `heddle generate "wrap the Gitea API"` → valid config in 20s | LLM can write code but can't validate it | Not designed for LLM generation | Visual-only, not scriptable |
| **Credentials** | `{{secret:key}}` resolved at runtime, never in config | Hardcoded or env vars | Hardcoded or env vars | Platform credential store |
| **Audit trail** | Hash-chained, tamper-evident, anomaly-flagged, every call logged | You build it yourself | None | Platform logs only |
| **Composability** | Configs become MCP tools, mesh them together | Manual wiring | Separate services | Workflow-scoped |
Heddle is for exposing APIs as MCP tools with real runtime controls — not just connectivity. If you only need one tool with no policy layer, hand-written FastMCP is simpler. If you need a visual workflow builder, use n8n. Heddle sits between those worlds: declarative like a workflow tool, programmable like a framework, secure by default.
---
## How It Works
Current Status
**Latest release:** [v0.2.1 — assurance release](https://github.com/goweft/heddle/releases/tag/v0.2.1). After v0.2.0, the codebase went through two independent AI-assisted security reviews plus a manual pass; every finding is closed, with regression tests pinning each one down — 273 tests total.
What Heddle can do today, what is partially implemented, and what is still planned:
| Layer | Status | Detail |
|:-----:|:------:|:-------|
| Config → MCP server | **Shipped** | YAML configs become typed MCP tools with HTTP bridging |
| Trust tiers (T1–T4) | **Shipped** | Runtime-enforced, violations blocked and logged |
| Credential broker | **Shipped** | Per-config secret policy, `{{secret:key}}` resolution |
| Audit logging | **Shipped** | Hash-chained JSON Lines, tamper-evident |
| Input validation | **Shipped** | Type checking, injection detection, rate limiting |
| Access mode annotations | **Shipped** | read/write on tools, T1 write blocked at load + runtime |
| Escalation rules | **Shipped** | Conditional hold-for-review on parameter thresholds |
| Config signing | **Shipped** | HMAC-SHA256, tamper detection |
| Config quarantine | **Shipped** | AI-generated configs staged for review |
| AI config generator | **Shipped** | Natural language → validated YAML via local LLM |
| Container sandboxing | **Shipped** | Docker-based isolation with hardening flags, image digest pinning, watchdog |
| Anomaly detection | **Shipped** | Novel tool calls, rate-limit breaches, repeated credential denials |
| Registry integrity | **Shipped** | Per-row HMAC verification, `heddle reg verify` |
| Network isolation | **Partial** | `--network=none` baseline shipped; per-host nftables enforcement planned (v0.3) |
## Core Features
### Declarative Tool Configs
Define tools in YAML. Heddle validates the config with Pydantic, generates typed MCP tools, and bridges HTTP with `{{param}}` template rendering. Cross-field validation catches bad configs before they run.
### AI Config Generator
Describe what you need in plain English. A local LLM generates valid YAML, Heddle validates it against schema rules, retries on failure, and saves the result.
```bash
$ heddle generate "agent that wraps the Gitea API" --model qwen3:14b
✓ Generated gitea-api-bridge.yaml (2 tools) in 20.3s
```
Security Architecture
Heddle's security controls map to the OWASP Top 10 for Agentic Applications (2026), NIST AI RMF, and MAESTRO. See the full [threat model](docs/threat-model.md) and [security controls reference](docs/security-controls.md).
| Control | What It Does | Framework |
|:-------:|:-------------|:---------:|
| **Trust tiers** | 4 levels (observer → privileged), runtime-enforced, violations blocked and logged | OWASP ASI03 |
| **Credential broker** | Per-config secret access policy, `{{secret:key}}` resolved at runtime, never stored in YAML | OWASP ASI03 |
| **Audit log** | Hash-chained JSON Lines, tamper-evident, 5 event types, secret redaction | OWASP ASI10 |
| **Input validation** | Type checking, length limits, injection pattern detection (shell, SQL, LLM prompt) | OWASP ASI01 |
| **Config signing** | HMAC-SHA256 on all agent configs, tamper detection | OWASP ASI04 |
| **Config quarantine** | AI-generated configs staged for review before promotion | OWASP ASI04 |
| **Rate limiting** | Sliding window per-config per-tool | OWASP ASI08 |
| **Container sandboxing** | Docker isolation: `--cap-drop=ALL`, `--no-new-privileges`, `--read-only`, pids limit, image digest pinning, watchdog timeout | OWASP ASI05 |
| **Anomaly detection** | Flags novel tool calls, rate-limit breaches, repeated credential denials via audit observer | OWASP ASI10 |
| **Registry integrity** | Per-row HMAC-SHA256 on agent registry, `heddle reg verify` detects tampering | OWASP ASI04 |
| **Escalation rules** | Conditional hold-for-review when parameters match thresholds or patterns | OWASP ASI02 |
---
## Starter Packs
Ready-made configs for common services. Copy one into `agents/`, update the base URL or credentials, validate, and run. See [packs/](packs/) for full docs.
| Pack | Tools | Trust | Description |
|:-----|:------|:------|:------------|
| [prometheus](packs/prometheus.yaml) | 5 | T1 read-only | PromQL queries, targets, alerts, metric discovery |
| [grafana](packs/grafana.yaml) | 5 | T1 read-only | Dashboards, datasources, alert rules |
| [git-forge](packs/git-forge.yaml) | 3 | T1 read-only | Repos, issues (Gitea/GitHub/Forgejo) |
| [ollama](packs/ollama.yaml) | 4 | T2 worker | Model listing, text generation, VRAM status |
| [sonarr](packs/sonarr.yaml) | 6 | T1 read-only | TV library, download queue, search, calendar, history |
| [radarr](packs/radarr.yaml) | 6 | T1 read-only | Movie library, download queue, search, calendar, history |
```bash
cp packs/prometheus.yaml agents/
heddle validate agents/prometheus.yaml
heddle run agents/prometheus.yaml --port 8200
```
## Advanced Examples
These show Heddle beyond simple API bridging.
### Tool Mesh
Multiple configs share a single MCP connection to Claude Desktop. The mesh launcher loads all configs, merges tools, and serves them through one stdio transport.
### VRAM Orchestrator
A higher-trust agent that manages GPU memory across Ollama and a local GGUF model library, including smart loading and automatic eviction when VRAM is constrained.
### Daily Ops Orchestrator
An orchestration agent that queries Prometheus, a RAG search API, and Ollama in parallel, then synthesizes a daily operations briefing with a local model.
### Web Dashboard
A FastAPI + React dashboard for mesh topology, agent status, live audit stream, credential policy, and config signatures.
---
Quick Start
### Clone and install
```bash
git clone https://github.com/goweft/heddle.git
cd heddle
python -m venv venv
source venv/bin/activate
pip install -e ".[dev]"
```
### Validate and run a config
```bash
heddle validate agents/prometheus-bridge.yaml
heddle run agents/prometheus-bridge.yaml --port 8200
```
### Generate a new config
```bash
heddle generate "agent that wraps the weather API at localhost:5000"
```
### Run the full mesh
```bash
heddle mesh agents/
```
### Security operations
```bash
heddle audit show -n 20
heddle audit verify
heddle sign all agents/
heddle sign verify agents/
heddle secrets policy
heddle sandbox agents/my-agent.yaml
```
### Audit log lifecycle
Heddle's audit log at `~/.heddle/audit/audit.jsonl` is a hash-chained JSONL file: every entry includes the SHA-256 of the previous entry, so a single tampered or missing line invalidates the chain from that point on. `heddle audit verify` walks the chain and exits non-zero on the first break.
**Policy: rotate-on-break, not tolerate-and-document.** A hash chain is either whole or it is broken; there is no useful middle ground. If `heddle audit verify` reports a break, the chain is sealed and a fresh one is started — the broken file is preserved as raw event data but is no longer the active chain. We do **not** carry a "known break, please ignore" exception forward, because each such exception weakens what `verify` is claiming and forces every consumer (CI, anomaly detection, future auditors) to special-case it.
**When you'd rotate:**
- `heddle audit verify` reports a break (most commonly from concurrent writers without file locking — fixed for new entries in v0.2.0 via an exclusive file lock in `_write_entry`, but historical breaks pre-dating that release remain).
- The active log has grown unwieldy (hundreds of MB) and you want an archive cut at a known-good boundary.
- You're cutting a release and want a clean baseline chain for the next development cycle.
**Manual rotation procedure** (until `heddle audit rotate` lands; see below):
```bash
# 1. Stop the broker so no writer is active
systemctl --user stop heddle-dashboard.service # or just kill heddle-mesh / dashboard
# 2. Capture a seal record alongside the file
cd ~/.heddle/audit
SEAL_DATE=$(date -u +%Y-%m-%dT%H-%M-%SZ)
sha256sum audit.jsonl > "audit-archive-${SEAL_DATE}.sha256"
wc -l audit.jsonl >> "audit-archive-${SEAL_DATE}.sha256"
# 3. Move the broken/old chain aside
mv audit.jsonl "audit-archive-${SEAL_DATE}.jsonl"
# 4. Restart the broker; the next event creates a fresh audit.jsonl
systemctl --user start heddle-dashboard.service
# 5. Verify the new chain
heddle audit verify # should exit clean immediately
```
Archived chains are kept in the same directory (they're still useful as event history) but are not re-verified by `heddle audit verify` — that command only walks the active chain. To inspect a sealed file directly, `jq -c '. | {ts, event, agent}' audit-archive-.jsonl` reads it as plain JSONL.
**Existing 2026-03-29 break:** development machines that ran the dashboard plus the test suite concurrently before the file-lock fix landed have a chain break around that date. There is no recovery path for the contiguous chain; rotating per the procedure above is the supported answer. Production-equivalent deployments (single broker writer, file locking present) should not see new breaks.
**Tracked follow-up:** `heddle audit rotate` is planned for v0.3. It will (a) atomically rename the active file to a timestamped archive, (b) write a `.sha256` seal alongside, and (c) seed the fresh chain with a `chain_seal_predecessor` event whose payload references the archive's hash so that an external auditor can chain the archives together. Until then, the manual procedure above is the documented path.
### Claude Desktop Integration
To expose a unified Heddle mesh to Claude Desktop (and optionally to [CAS](https://github.com/goweft/cas)):
```json
{
"mcpServers": {
"heddle-mesh": {
"command": "/path/to/heddle/venv/bin/heddle-mesh"
}
}
}
```
## CLI Reference
| Command | Description |
|:--------|:------------|
| `heddle run ` | Run a single agent from YAML |
| `heddle validate ` | Validate a config without running it |
| `heddle generate ""` | Generate a config from natural language |
| `heddle mesh ` | Start all agents as a unified mesh |
| `heddle list` | List registered agents |
| `heddle registry` | Show all registered tools |
| `heddle info ` | Show detailed agent info |
| `heddle probe ` | Discover tools on a running MCP server |
| `heddle audit show` | Inspect audit log entries |
| `heddle audit verify` | Verify hash chain integrity |
| `heddle secrets` | Manage credential broker |
| `heddle sign` | Sign and verify configs |
| `heddle quarantine` | Stage AI-generated configs for review |
| `heddle sandbox ` | Show generated sandbox configuration |
| `heddle reg verify` | Verify HMAC integrity of all registry rows |
| `heddle reg resign` | Recompute HMACs for all registry rows |
## Project Structure
```text
heddle/
├── agents/ # YAML agent configs
├── packs/ # Starter pack configs
├── docs/
│ ├── threat-model.md # Threat analysis, framework-mapped
│ └── security-controls.md
├── src/heddle/
│ ├── cli.py # CLI entrypoint
│ ├── config/ # Pydantic schema and YAML loader
│ ├── mcp/ # MCP server builder, client, registry
│ ├── runtime/ # Agent runner and mesh runtime
│ ├── generator/ # AI config generator and API discovery
│ ├── security/ # Trust, credentials, audit, validation,
│ │ # signing, sandbox, escalation
│ ├── agents/ # Custom higher-level handlers
│ └── web/ # Dashboard backend and frontend
├── tests/
└── pyproject.toml # Entry points: heddle, heddle-dashboard, heddle-mesh
```
## Tech Stack
Python 3.11+ · FastMCP · FastAPI · Pydantic v2 · httpx · Click · SQLite · Ollama
## The WEFT Ecosystem
Heddle is the trust and policy layer. The rest of the stack:
| Project | Language | What it does |
|---|---|---|
| **[cas](https://github.com/goweft/cas)** | Go | Conversational Agent Shell — terminal TUI where conversation generates workspaces. Heddle adds optional trust enforcement and audit logging. |
| **[tenter](https://github.com/goweft/tenter)** | Python | Pre-publish artifact scanner — catches source maps, secrets, debug artifacts before they ship. On GitHub Marketplace. |
| **[tenter-rs](https://github.com/goweft/tenter-rs)** | Rust | tenter v2 — static binary, no runtime required. |
| **[unshear](https://github.com/goweft/unshear)** | Rust | Fork divergence detector — reveals where safety mechanisms were stripped from a forked agent codebase. |
| **[ratine](https://github.com/goweft/ratine)** | Python | Agent memory poisoning detector. |
| **[crocking](https://github.com/goweft/crocking)** | Python | AI authorship detector for git repositories. |
### Heddle + CAS
CAS runs standalone. Heddle integration is optional and adds:
- **Trust enforcement** — every tool call CAS makes passes through Heddle's tier system
- **Credential brokering** — `{{secret:key}}` resolution, credentials never in config
- **Audit logging** — hash-chained, tamper-evident record of every workspace operation
```json
{
"mcpServers": {
"heddle-mesh": {
"command": "/path/to/heddle/venv/bin/heddle-mesh"
}
}
}
```
## License
MIT — see [LICENSE](LICENSE).
