Big data is evolving  in a big way. As it booms, the issue of fault  tolerance  becomes more and more exigent. What happens if a node fails? Will your application recover from the effects of data or process corruption?

In a conventional world, the simplest solution for such a problem would have been a restart of the offending processes from the beginning. However, that was the conventional world, with data sizes still within the reach of imagination. In the world of big data, the size of data cannot be imagined. Let alone imagine, the growth is almost incomprehensible.  A complete restart would mean wasting precious resources, be it time, or CPU capacity. Such a restart in a real-time scenario would also be unpredictable. After all, how do you recover data that changed by the second (or even less) accurately?

Fault tolerance  is not just a need, it is an absolute necessity. The lack of a fault tolerance mechanism affects SLAs. A system can be made fault-tolerant by using checkpointing. You can think of a checkpointing mechanism as a recovery process; a system process saves snapshots  of application states periodically, and uses these snapshots for recovery in case of failures. A  platform developer alone should ensure that a big data platform is checkpointcompliant. Application developers should only be concerned with their business logic, thus ensuring clear distinction between operability and functional behavior.

Apex treats checkpointing as a native function, allowing application developers to stop worrying about application consistency.

Apache ®  Apex does checkpointing intelligently, while relieving application developers of the need to worry about their platforms being failsafe.  By transparently checkpointing the state of operators to HDFS periodically, Apex ensures that the operators are recoverable on any node within a cluster. The Apex infrastructure is designed to scale, while ensuring easy recovery at any point during failure. The Apex checkpointing mechanism uses the DFS interface. thereby being agnostic to the DFS implementation.

Apex introduces checkpointing by maintaining operator states within HDFS.

Apex serializes the state of operators to local disks, and then asynchronously copies serialized state to HDFS. The state is asynchronously copied to HDFS in order to ensure that the performance of applications is not affected by the HDFS latency. An operator is considered “checkpointed” only after the serialized state is copied to HDFS. In case of Exactly-Once recovery mechanism, platform checkpoints at every window boundary and it behaves in synchronous mode i.e the operator is blocked till the state is copied to HDFS.

Although Apex is designed to checkpoint at window boundaries, developers can control how optimal a checkpoint operation is.  Developers can control how often checkpointing is triggered. They can do this by configuring the window boundary at which checkpointing will occur, by using the CHECKPOINT_WINDOW_COUNT  attribute. Frequent checkpoints hamper the overall application performance. This is in stark contrast to sparsely placed checkpoints, which are dangerous because they might make application recovery a time-consuming  task.

See this example to see how the apex checkpointing mechanism works.

In our example, let us set CHECKPOINT_WINDOW_COUNT to 1. This diagram shows the flow of data within window boundaries.  You will see that at the end of each window, Apex checkpoints data in order to ensure that it is consistent. If the operator crashes during window n+1, Apex restores it to nearest stable state, in this example, the state obtained by introducing checkpointing at the end of window n. The operator now starts processing window n+1 from the beginning. If CHECKPOINT_WINDOW_COUNT was set to 2, then there would have been one checkpoint before window n, and another checkpoint after window n+1.


Judicious checkpointing ensures optimum application performance

Checkpointing is a costly and a resource-intensive operation, indicating that an overindulgence will impact an application’s performance. To  act as a deterrent to the performance slowdown because of checkpointing, Apex checkpoints non-transient data only.  For example, in JDBC operator, connection can be reinitialized at the time of setup, it should be marked as transient, and thus omitted from getting checkpointed.

Application developers must know whether  to checkpoint or not; the thumb rule dictates that operators  for which computation depends on the previous state must be checkpointed. An example is the Counter operator, which tracks the number of tuples processed by the system. Because the operator relies on its previous state to proceed, it  needs to be checkpointed. Some operators are stateless; their computation does not depend on the previous state. Application developers can omit such operators from checkpointing operations by using the STATELESS  attribute or by annotating the operator with Stateless.
