# Shape Shifter
[![Build Status][travis-badge]][travis-badge-url]
[![Coverage Status][coveralls-badge]][coveralls-badge-url]
[](http://githubstats.com/alexjlockwood/ShapeShifter)
**[Go to live version](https://shapeshifter.design)** or **[ask a question on Slack](https://join.slack.com/t/shapeshifterdesign/shared_invite/enQtNDAwODY5NjI2NTE4LTAyZTE3ZmYxNGUxMmViY2UwNDJjZWYyYzhhNTQzYmVkYmVmNTA0NmEyY2MwMmFiOTllODI5YzZmNDQwOTE1MGU)**
-----
[Shape Shifter](https://alexjlockwood.github.io/ShapeShifter/) is a web-app that simplifies
the creation of [icon animations][adp-icon-animations] for Android, iOS, and the web.
This tool currently exports to standalone SVGs, SVG spritesheets,
and CSS keyframe animations for the web, as well as to
[`AnimatedVectorDrawable`](https://developer.android.com/reference/android/graphics/drawable/AnimatedVectorDrawable.html)
format for Android. I am totally open to adding support for other export formats as well, so
if you have a format that you'd like to see added in the future,
file a [feature request][report-feature-request]!
Try out the [beta version](https://beta.shapeshifter.design), which adds the ability to draw/edit paths directly on the canvas (written using the amazing [paper.js](http://paperjs.org/) library)!
## Backers
Support us with either a one time donation or a monthly donation and help us
continue our activities. Funds will go towards hiring new developers to work
on awesome features! We'll display your logo below with a link to your site.
🙏 [Become a backer](https://opencollective.com/shapeshifter#backer) 🙏
## Sponsors
Is your company using Shape Shifter? Ask your manager to support us!
We'll display your logo below with a link to your site.
🙏 [Become a sponsor](https://opencollective.com/shapeshifter#sponsor) 🙏
## Examples
I gave a couple of live demos that illustrate how to use the tool at Droidcon SF ([15:15 - 20:33](https://youtu.be/JhryKMOM6GI?t=15m15s)):
[](https://youtu.be/JhryKMOM6GI?t=15m15s)
Here are some example icon animations created by Shape Shifter:
## Problem
Writing high-quality [path morphing animations][adp-path-morphing]
is a tedious and time-consuming task. In order to morph one shape into another,
the SVG paths describing the two must be *compatible* with each other—that is,
they need to have the same number and type of drawing commands. This is problematic because:
* Design tools—such as [Sketch][sketch] and [Illustrator][illustrator]—do not easily
expose the order of points in a shape, making it difficult to change their order. As a result,
engineers will often have to spend time tweaking the raw SVG path strings given to them by
designers before they can be morphed, which can take a significant amount of time.
* Design tools often map to shape primitives not supported in certain platforms
(e.g. circles need to be represented by a sequence of curves and/or arcs,
not simply by their center point and radius).
* Design tools cannot place multiple path points in the same location, a technique that
is often necessary when making two shapes compatible with each other.
* Design tools provide no easy way to visualize the in-between states of the desired
path morph animation.
## Features
To address these problems, Shape Shifter provides the following features:
* *The ability to add/remove points to each path without altering their original appearance.*
The added points can be modified by dragging them to different positions along the path,
and they can be later deleted using the keyboard as well.
* *The ability to reverse/shift the relative positions of each path's points.* While reordering points
won't affect whether or not two paths are compatible, it often plays a huge role in determining the
appearance of the resulting animation.
* *Shape Shifter automatically converts incompatible pairs of SVG commands into a compatible
format.* There's no longer any need to convert `L`s into `Q`s and `A`s into `C`s by hand in
order to make your paths compatible—Shape Shifter does this for you behind-the-scenes!
* *Shape Shifter provides a useful utility called 'auto fix', which takes two incompatible
paths and attempts to make them compatible in an optimal way.* Depending on the complexity
of the paths, auto fix may or may not generate a satisfying final result, so further
modification may be necessary in order to achieve the animation you're looking for.
* *The ability to export the results to SVG spritesheets, CSS keyframes, and
`AnimatedVectorDrawable` format for use on
the web and in Android applications.* I'm open to adding support for other export formats
as well, so feel free to file a [feature request][report-feature-request]!
## How does it work?
Pretty much all of the graphics in this app are powered by bezier curve approximations under-the-hood.
I learned most of what I needed to know from this excellent [primer on bezier curves][primer-on-bezier-curves]
(especially sections 9 and 33, which explain how to split and project points onto bezier
curves without altering their original appearance). Most of the interesting SVG-related code
is located under [`src/app/model/paths`](https://github.com/alexjlockwood/ShapeShifter/tree/master/src/app/model/paths).
Auto fix is powered by an adaptation of the [Needleman-Wunsch algorithm][Needleman-Wunsch],
which is used in bioinformatics to align protein or nucleotide sequences. Instead of
aligning DNA base-pairs, Shape Shifter aligns the individual SVG commands that make up
each path instead. You can view the current implementation of the algorithm in the
[`AutoAwesome.ts`](https://github.com/alexjlockwood/ShapeShifter/blob/master/src/app/scripts/algorithms/AutoAwesome.ts) file.
## Bug reports & feature requests
Let me know if you encounter any issues with the app (attach SVG files and/or
screenshots if you can). Before you do, take a look at the list of known issues
[here](https://github.com/alexjlockwood/ShapeShifter/issues) and leave a comment
on the existing bugs you want to see fixed in a future release!
I am open to pretty much any feature request, so don't be afraid to ask!
I'll likely work on the most popular feature requests first. **I'm especially
curious how I can make this web app more useful for iOS and web developers.**
## Build instructions
If you want to contribute, you can build and serve the web app locally as follows:
1. First install [`Node.js`](https://nodejs.org/) and [`npm`](https://www.npmjs.com/).
2. Clone the repository and in the root directory, run:
```
npm install
```
3. To build and serve the web app locally, run:
```
npm start
```
## Special thanks
Huge thanks to [Nick Butcher][nick-butcher-twitter], [Roman Nurik][roman-nurik-twitter],
and [Steph Yim][steph-yim-website] for all of their help during the early stages of this project!
